Number of slots; from 50 to 800 Number of drives; from 1 to 24 Supported drive types;Full-Height (FH) LTO drives

LTO-9 (standard / compressed); 900 to 14,400 / 2,250 to 36,000 LTO-8 (standard / compressed); 600 to 9,600 / 1,500 to 24,000 LTO-7 (standard / compressed); 300 to 4,800 / 750 to 12,000

Module form factor;Rackmount (6U) Minimum size;One module (6U) Maximum size;Eight modules (48U) Accommodation;Only in the rack Scalability; Rackmountable up to 48U / incremental by 6U and 25 slots (CoD licensing)

Inventory speed; From 1 to 6 minutes (depending on configuration) Upgrade modules; Any module can be added in less than 30 minutes Rack Mounting Requirements;The library must be mounted in a standard 19-inch rack with support for a depth of 36.4 inches (92.5 cm) Insertion/extraction options;Customizable: 0 to 240 slots (incremental by 5 slots)

Drive interfaces; 8 Gb optical and 12 Gb SAS (LTO-9 only) Management interface;Dual 1 GbE Library Interface; End-to-end Data Bridge drives, 1 GbE with remote GUI and RESTful web services for library management

MSBF;More than 2 million MTTR;30 minutes Voltage;100 to 240 VAC, 50 to 60 Hz Power supply;Optional 2N/80 PLUS Gold certified power supplies Dual robotization;No

Control module; 10.4 in x 17.4 in x 36.4 in (26.4 cm x 44.1 cm x 92.45 cm) Expansion module; 10.4 in x 17.4 in x 36.4 in (26.4 cm x 44.1 cm x 92.45 cm) Parking module;Not present

Temperature

Recommended;LTO-7, LTO-8: 16 to 25°C (61 to 77°F), LTO-9: 15 to 25°C (59 to 77°F) Acceptable;LTO-7, LTO-8: 16 to 35 °C (61 to 95 °F), LTO-9: 15 to 35 °C (59 to 95 °F) For delivery conditions;-23 to 49 °C (-9 to 120 °F)

Relative humidity

Recommended; 20 to 50% (non-condensing) Permissible; from 20 to 80% (non-condensing) For delivery conditions;5 to 80% (non-condensing)

Maximum temperature difference

Recommended;5°C/hour Acceptable;5 °C / hour

Maximum change in humidity

Recommended;5%/hour Acceptable; 5% / hour

Temperature limits according to humidity

Recommended;LTO-7, LTO-8: Dry Bulb Temp <= 26°C (79°F), LTO-9: Max. dew point 22°C (72°F) Acceptable;LTO-7, LTO-8: Dry Bulb Temp <= 26°C (79°F), LTO-9: Max. dew point 22°C (72°F) For delivery conditions;Dry bulb temp. <= 26 °C (79 °F)

Maximum height

Permissible;3,048 m (10,000 ft) For delivery conditions;12,192 m (40,000 ft)

Safety standards; IEC 60950-1 and IEC 62368-1 with international differences, EN62368-1, UL 62368-1, IS3525(Part 1), CNS14336-1 Emission standards;FCC Part 15 Class A, EN 55032 Class A, KN 32, VCCI, EN 300 386, CNS 13438 Class A, ICES-003 Class A Noise immunity;EN 55024, KN 35; KN24
